In 2017 Honda made changes to the front suspension that removed the built-in camber adjustment and added the need to move the control arms down to install a lift kit. Traxda has addressed both these issues with their 2" lift kit. Traxda strut spacers have 2 degrees (+1/-1) of camber adjustment built in. This also makes for easier installation. On the Hondas, to prevent the front axles from contacting the bolts that hold the lower control arms, a spacer is included to avoid contact. In addition, the factory sway bar links are replaced with shorter links to prevent the sway bar from contact with the frame at full extension.
You can rely on Traxda products as they use only the very best materials to build their lift components. Traxda lift kits are manufactured in the USA, on site at their warehouse, using CNC machinery and robotic welding for precision fits.
Kit Features
Designed to retain the stock ride quality
Aftermarket struts are not required
Alignment specs included, CAMBER adjustment built in to Traxda kit
MADE IN THE USA
View kit installation instructions
Traxda lift kit fits the following 4WD, 2WD and AWD models:
2017 Honda Ridgeline
2018 Honda Ridgeline
2019 Honda Ridgeline
2020 Honda Ridgeline
2021 Honda Ridgeline
2022 Honda Ridgeline
2023 Honda Ridgeline
2024 Honda Ridgeline
2016 Honda Pilot
2017 Honda Pilot
2018 Honda Pilot
2019 Honda Pilot
2020 Honda Pilot
2021 Honda Pilot
2022 Honda Pilot
2017 Honda Passport
2018 Honda Passport
2019 Honda Passport
2020 Honda Passport
2021 Honda Passport
2022 Honda Passport
2023 Honda Passport
2024 Honda Passport
Not all 31" tires are the same. Therefore, to avoid rubbing, stay under 31" tall and under 10" wide. Traxda used 265/65-18 tires on 18x8 wheels with a +38mm offset that resulted in slight rubbing when backing up or turning left. To avoid rubbing altogether, use 265/65-18 with stock wheels (offset +55mm) with slight rubbing that was reduced by trimming the plastic at the rear of the wheel well. Further reduce rubbing by installing a wheel spacer that changes the offset by 16mm
